Common models: LMO14.../LMO24.../LMO44...
Product Description:
Oil burner with forced draft intermittent operation based on microprocessor control
LMO14.../LMO24...less than 30Kg/h
LMO44...greater than 30Kg/h, and used for stationary direct-fired air heaters
Technical parameters - Siemens LMO series oil burner controller
Model Rated voltage Number of solenoid valves Burner output Preheater interface Working hours Similar models
tw t1 TSAm t3 t3n t4
LMO14.111A2 AC230V 1 <30kg/h Yes 5s 16s 10s 15s 10s - LOA24.171B27
LOA26.171B27
LOA36.171A27
LMO14.111A1 AC110V 1 <30kg/h Yes 5s 16s 10s 15s 10s - LOA24.171B17
LMO14.113A2 AC230V 1 <30kg/h Yes 5s 16s 10s 15s 3s - LOA24.173A27
LMO24.111A2 AC230V 2 <30kg/h Yes 5s 16s 10s 15s 10s 15s LOA24.171B27
LOA26.171B27
LOA36.171A27
LMO24.111A1 AC110V 2 <30kg/h Yes 5s 16s 10s 15s 10s 15s LOA24.171B17
LMO24.113A2 AC230V 2 <30kg/h Yes 5s 16s 10s 15s 3s 15s LOA24.173A27
LMO24.011A2 AC230V 2 <30kg/h Yes 5s 6s 10s 5s 10s 15s LOA24.571C27
LMO44.255A2 AC230V 2 >30kg/h Yes 5s 26s 5s 5s 25s 5s LOA44.252A27
TSAm: maximum ignition safety time
tw: waiting time
t1: pre-purge time
t3: pre-ignition time
t3n: ignition process time
t4: Internal cycle time from flame signal to release
