Many of our current smart technologies rely on the Internet to control our equipment in a program-intelligent way. For example, the display method of the electronic display depends on the compilation of Internet programs. Let's take a look at the operation of the natural gas boiler control system. way.
1. The combustion and operation of the natural gas boiler is controlled by a microcomputer control system. It uses modern computer CPU control technology. It has a powerful CPU processor that can concentrate all programs on a digital chip. The function is very powerful, and its degree of automation is very high. The display screen is a large full-length Chinese LCD screen with high brightness. The image shows the water level, the degree of heating, the status of the pump valve and the alarm status in the form of animation. If the water level of the boiler is too low or too high, the controller will give an alarm. At this time, we have to check the water pump control system, repair the water level probe control line or replace the water level probe.
2. The controller is powered by the power circuit, and the sensor group and flame probe installed on the monitoring part of the natural gas boiler burner and thermal system convert the working state of the monitoring part into an electrical signal or digital signal output; the flame monitoring circuit, input The terminal is connected to the flame probe, and the output terminal is connected to the control execution circuit, which amplifies the electrical signal output by the flame probe and converts it into a digital signal for output; the input terminal of the power monitoring circuit is connected to the power circuit for monitoring the voltage of the power circuit.
3. Logic judgment circuit, the input terminal is connected to the power monitoring circuit and the sensor group. This circuit is used to judge the electrical signal output by the sensor group connected to the natural gas boiler and the working state of the connected circuit to judge and output; it also includes a control line circuit, The input terminal is connected with a flame monitoring circuit, a logic judgment circuit and a sensor group. The circuit judges the input digital signal, outputs a control signal, and the execution unit completes the instruction action.
The control system of the natural gas boiler only needs to run normally according to the compiled program, and then the boiler does not need human support during operation, and it will run automatically. This intelligent technology has been applied to many equipment, saving a lot of manpower for the enterprise resource.
