1. Instructions for use Turn on the power, start the burner motor, and generate electric sparks between the ignition electrodes. After pre-blowing, the solenoid valve of the oil pump will automatically open, and the oil mist from the nozzle will be ignited to form a flame after being broken down by the electric sparks. At this time, the flame detector feels the brightness of the flame, and the controller enters the locked state. After the ignition electrode delays the ignition, the ignition is stopped, and the burner enters the normal working state. If the ignition is unsuccessful, no flame is formed, or the flame detector does not feel the brightness of the flame, after the safety time passes, the safety alarm system will operate, the starting working procedure of the burner will be cut off, and the fault red light will be on. When the burner is just started, if the flame detector has felt the brightness, the safety system will operate, the controller will not enter the normal program, the solenoid valve will not open, the nozzle will not inject oil, and the fault red light will be on after the safety time. Therefore, when starting the burner in a bright place, the flame detector must be covered first to prevent it from seeing light. After the burner emits flames, release the flame detector immediately, otherwise the burner will not work normally. The burner can be restarted after the red light of the burner is on for 3 minutes.
2. Matters needing attention, when connecting peripheral circuits, and realizing automatic control of boiler temperature, pressure, water level, etc., please connect according to the wiring diagram of the control system. The oil suction pipe should not be close to the bottom of the fuel tank, and a distance of 80-120mm should be kept. The burner should be turned off before filling the fuel tank, and the fuel can be injected into the fuel tank after being filtered, and can be restarted after 20 minutes of fuel filling. The oil system must not leak oil or air. Check whether the fuel tank is sufficient before starting the burner. The damper size should match the nozzle specification. When the burner is in use, since the equipped boiler is inconsistent with the boiler used for debugging when the burner leaves the factory, it is generally necessary to properly adjust the damper, and sometimes it is necessary to replace the oil nozzle with appropriate specifications and spray angles. The ambient temperature of the burner must not exceed 70°C, otherwise cooling and heat insulation measures should be taken. When used in colder regions, appropriate thermal insulation measures should be taken for the oil storage device and the oil supply and return pipeline system to prevent the oil circuit from being blocked due to freezing. At the same time, the control circuit part of the burner must not be exposed to moisture or high temperature. Turn off the burner when sweeping the chimney. The motor and ignition transformer should be protected from moisture and should not be used in a humid environment. The burner should be installed in balance, and should be used horizontally or vertically, avoiding inclined use. When it is inconvenient to directly operate the burner, the control switch and electrical protection device should be connected externally. Always check whether the connection of the burner and various components is firm, whether it is loose, and whether the position has changed. When the burner is started, be careful to prevent the sudden flame from hurting people and destroying things.
3. For regular maintenance, the light diesel oil used must be clean, please pay attention to regular cleaning of the fuel tank and oil filter. . Under normal use, replace the oil nipple once a year, and replace the elastic coupling and the rubber parts on the coupling once a year and a half. It is strictly forbidden for foreign matter to enter the air duct. The site where the burner is used should be kept away from flammable and explosive materials, and fire extinguishing equipment should be provided. Adjust the oil pressure appropriately according to the indicated value of the oil pressure. Regularly check the combustion cylinder, impeller, flame detector and ignition electrode to remove oil and carbon deposits. In particular, the flame detector should be kept clean and must not be exposed to water. Be sure to cut off the power supply when maintaining the burner.
