As a mechatronic mechanical equipment with high automation control level, the burner can be divided into five major systems from its functions: air supply system, ignition system, monitoring system, fuel system, and electric control system.
1. Air supply system
The function of the air supply system mobile phone software is to send gas with a certain wind speed and air volume into the combustion chamber of the engine. Its important prefabricated components include: body, fan motor, fan impeller, air gun fire tube, damper controller, damper baffle, Diffuser disc.
2. Ignition system
The function of the ignition system is to ignite the chemical substances of gas and fuel. Its important prefabricated components include: ignition transformer, ignition power plant level, and electric fire high-voltage cables.
3. Monitoring system
The function of the monitoring system is to ensure the operation of the safety factor of the burner. Its important prefabricated components include flame detectors, pressure detectors, and inspection thermometers.
4. Fuel system
The role of the fuel system software depends on ensuring that the burner ignites the required fuel. The fuel system software of the fuel burner mainly includes: oil pipes and joints, oil pumps, solenoid valves, nozzles, and heavy oil preheaters. Gas burners mainly include filters, pressure regulators, solenoid valve groups, and ignition solenoid valve groups.
5. Electric control system
The electronic control system is the command system and communication center of the above systems. The main hydraulic control system is a program controller. Different program controllers are installed for different burners. The common program controllers are: LFL series , LAL series, LOA series, LGB series, the main difference is that the time of each program step is different.
